Stainless steel welded wire mesh specification diagram

Views: 566     Author: Site Editor     Publish Time: 2017-05-18      Origin: Site

Stainless steel welded wire mesh is manufactured from 304 grade or 316 grade stainless steel wire in various diameters. The longitudinal and transverse wires are then resistance welded together to create a functional mesh product. This is supplied in rolls or panels. Special sizes and types can also be manufactured subject to material availability.

Stainless steel welded wire mesh

Design Size: 6.3mm x 6.3mm
Wire Diameter: 0.8mm
Aperture: 5.5mm x 5.5mm

Wire Diameter: 0.8mm
Aperture: 5.5mm x 5.5mm


Stainless steel welded wire meshDesign Size: 9.5mm x 9.5mm
Wire Diameter: 1mm
Aperture: 8.5mm x 8.5mm

Wire Diameter: 1mm
Aperture: 8.5mm x 8.5mm

Stainless steel welded wire mesh

Design Size: 12.7mm x 12.7mm
Wire Diameter: 1.2mm
Aperture: 11.5mm x 11.5mm

Wire Diameter: 1.2mm
Aperture: 11.5mm x 11.5mm


Stainless steel welded wire mesh

Design Size: 25.4mm x 12.7mm
Wire Diameter: 1.6mm
Aperture: 23.8mm x 11.1mm

Wire Diameter: 1.6mm
Aperture: 23.8mm x 11.1mm

Stainless steel welded wire mesh

Design Size: 25.4mm x 25.4mm
Wire Diameter: 2mm
Aperture: 23.4mm x 23.4mm

Wire Diameter: 2mm
Aperture: 23.4mm x 23.4mm


Stainless steel welded wire mesh

Design Size: 25.4mm x 25.4mm
Wire Diameter: 3mm
Aperture: 22.4mm x 22.4mm

Wire Diameter: 3mm
Aperture: 22.4mm x 22.4mm

Stainless steel welded wire mesh

Design Size: 40mm x 40mm
Wire Diameter: 3mm
Aperture: 37mm x 37mm

Wire Diameter: 3mm
Aperture: 37mm x 37mm



Stainless steel welded wire mesh

Design Size: 50.8mm x 50.8mm
Wire Diameter: 3mm
Aperture: 47.8mm x 47.8mm

Wire Diameter: 3mm
Aperture: 47.8mm x 47.8mm
Stainless steel welded wire meshDesign Size: 50.8mm x 50.8mm
Wire Diameter: 4mm
Aperture: 46.8mm x 46.8mm

Stainless steel welded wire meshDesign Size: 100mm x 100mm
Wire Diameter: 3mm
Aperture: 97mm x 97mm
Stainless steel welded wire meshDesign Size: 100mm x 100mm
Wire Diameter: 6mm
Aperture: 94mm x 94mm


Model Mesh size Wire Diameter Width Length
WM-001 6.3mm x 6.3mm 0.8mm 1220mm 5 metre roll
WM-002 9.5mm x 9.5mm 1mm 1220mm 5 metre roll
WM-003 12.7mm x 12.7mm 1.2mm 1220mm 5 metre roll
WM-004 12.7mm x 12.7mm 1.2mm 1220mm 30 metre roll
WM-005 12.7mm x 12.7mm 1.6mm 1220mm 5 metre roll
WM-006 12.7mm x 12.7mm 1.6mm 1220mm 30 metre roll
WM-007 12.7mm x 25.4mm 1.6mm 1200mm 2400mm sheet
WM-008 25.4mm x 25.4mm 3mm 1200mm 2400mm sheet
WM-009 40mm x 40mm 3mm 1200mm 2400mm sheet
WM-010 50.8mm x 50.8mm 3mm 1200mm 2400mm sheet
WM-011 50.8mm x 50.8mm 4mm 1200mm 2400mm sheet
WM-012 50mm x 50mm 5mm 1200mm 2400mm sheet
WM-013 100mm x 100mm 3mm 1200mm 2400mm sheet
WM-014 100mm x 100mm 6mm 1200mm 2400mm sheet
